Mining Stabilizing Anchor Plate 120*120*10

Product details:

There are two main types of anchor disks: square round hole anchor disks and round round hole anchor disks. By combining with the anchor rods inside the surrounding rock, the anchor disk changes the mechanical state of the surrounding rock itself, so as to form a whole and stable rock belt around the roadway. The purpose of maintaining the stability of the roadway is achieved by the joint action of the anchor rods and the surrounding rock.

In the field of mine support, anchor pan is widely used as an active defense support method. Through the use of anchor pan and anchor rods, the surrounding rock around the roadway can be effectively stabilized, and the overall support effect and safety can be improved. The application of anchor plates is a major change for the field of mine support, bringing positive impacts on the safety and stability of the working environment in mines.

Overall, anchor pans play a vital role in mine support, and through innovation and wide application, provide important support for the development and safety of mining projects. If you have any further questions or need further information, please feel free to let me know and I will try my best to support you.

Specifications and parameters：

Product Description.

Anchor disk is a kind of mine support material, which is used to cooperate with anchor rods for support. The design of anchor disk can be round, square or rhombic, and different shapes of anchor disk are selected according to the specific use scenarios and requirements. In environments such as mines, anchor pans are an important support material that can provide strong support where the surrounding rock is unstable or where support is needed.

The main function of the anchor disk is to be used together with the anchor rods to provide support and protection by placing the anchor disk in the rock mass and ensuring that it is in close contact with the rock mass. Different shapes of anchor disks can be applied to rock masses of different shapes or sizes to ensure the effectiveness and stability of the support system.

Usage, the following are the steps to use the anchor disk with the anchor metal rod and nut to form a set of anchor rods:

1. Determine the hole position of the anchor according to the design requirements, and use the drilling rig to drill the hole in the fixed position.

2. Use pressurized air equipment to blow the rock dust in the hole to ensure that the hole is clean.

3. Make sure the diameter of the rock hole is 6-12mm larger than the diameter of the anchor rod, leaving enough space to ensure the installation of the anchor rod.

4. Use the anchor rod to feed the anchoring agent into the bottom hole, start the mixing device for mixing, and strictly control the mixing time according to the requirements of the resin anchoring agent to ensure a uniform mix.

5. After waiting for proper time, set the anchor disk on the anchor rod and then tighten the nut to ensure the stability and firmness of the whole anchor system.

The above steps are the way to use the anchor disk with the anchor rods in the correct order. Please ensure that safety procedures are followed during operation to ensure safety and effectiveness during use. If you have any questions or need further assistance, please feel free to contact me.
