Superbly Bonded Quicklime-Cka

Product Details

Anchor agent is the use of high-strength anchor special unsaturated polyester resin and marble powder, accelerator and auxiliary materials, according to a certain proportion of the mastic-like bonding material, with special polyester film will be divided into two-component packaging with the curing agent medicine volume.

Product features:

1. Fast load bearing, anchoring performance similar to steel pre-buried parts. It has the characteristics of "two fast and one high", i.e. fast curing time (speed adjustable), fast strength growth and high strength. After installation, it can not only bear the load in time, but also has large anchoring force.

2. Resin anchoring agent adaptability, bonding object wide. Bonding shaped, complex large thin plate structure, can anchor a variety of wood, metal, fiberglass body and other rigid objects.

3. Good fatigue strength. Resin anchors can be widely used for structural reinforcement, rock support, equipment foundation fixing, dam crack repair and high-rise building exterior stone dry hanging, metal or curtain wall frame installation and fixing.

4. Water-resistant Resin anchoring agent in addition to the above characteristics, when there is the presence of water, has the characteristics of fast enhancement, high strength, to avoid the impact of water on the curing rate of resin anchoring agent, compressive strength and anchoring force.

Scope of application:

Resin anchoring agent is not only used in shaft support, shaft installation, pre-stressing anchor reinforcement for water and electricity projects, but also has its wide application place in the fields of building reinforcement, highway repair, tunnel construction, foundation rooting, equipment foundation and component anchoring.

Specifications and Parameters

Note: Specified under (22±1) C ambient temperature conditions.

Product Description

Resin anchoring agent is made of unsaturated polyester resin, curing agent, accelerator and different auxiliary materials, in accordance to a sure share of the viscous shape of anchoring bonding material, through polyester movie cut up packaging in the structure of medicinal drug rolls, with quickly curing at room temperature, excessive adhesive strength, dependable anchoring pressure and sturdiness and different top performance.

Usage:

1.According to the surrounding rock lithology, geological conditions, sketch anchor help parameters, in accordance to the necessities of development operations to pick out the resin anchoring agent specifications, models.
2.For the comfort of phrase anchor installation, the depth of drilling gap have to be 60~80mm much less than the size of anchor.
3.After the anchor gap is drilled, earlier than putting in the anchor, pressurized air ought to be used to do away with floating dirt and water in the hole.
4.Installation of anchor rods: use the anchor rod to slowly ship the anchoring agent to the backside of the hole, then begin the agitator to pressure the rod to rotate, enhance the rod to the backside of the gap at a uniform speed, combine and stir the two factors of the anchoring agent, and play the position of anchoring. Select the rotational pace of the mixing equipment ≥ r/min, and the mixing time is operated in accordance to the time distinct in Table I. It is strictly prohibited to flip on the mixer in the case that the anchoring agent is now not delivered to the backside of the hole.
5.After the give up of mixing, wedge the rod in time, and do no longer make the rod pass all through the ready time to make sure the pleasant of anchoring.
6.After assembly the ready time specific in Table I, the nut can be tightened on the pallet, and the designed anchoring pressure can be reached after achieving the bearing time.
7.Anchoring agent have to be cautiously checked earlier than use coloration and feel, tender texture, look intact can be used. If there is hardening, caking, rupture, deterioration and different odd phenomena, restrict the use.
8.After the installation, the anchoring satisfactory have to be checked, and the anchoring pressure need to be examined in accordance to the regulations. If the anchoring pressure is observed to be no longer in accordance with the requirements, remedial measures have to be taken.
