Mesh Steel Reinforcement
Advantage:
Mesh Masonry's anchor mesh products stand out in the market for their outstanding performance and reliability. In particular, Mesh Ref 193 and Mesh Ref 245 provide excellent structural support as well as superior corrosion resistance and durability for a wide range of harsh environments. In addition, Mesh Ref 245 Price is very competitive, offering customers a cost-effective option. Whether it's a construction or infrastructure project, choosing Mesh Masonry's anchor mesh products will ensure the long-term stability and safety of your project.
Product Description:
Mesh Masonry's anchor mesh products are well known in the construction industry for their superior quality and reliability. Our main products include Mesh Steel Reinforcement and welded wire Mesh, which play a key role in a variety of construction projects. Welded Wire Mesh is known for its uniform mesh design and strong welded joints, and is used in a wide range of applications such as wall reinforcement, floor support and foundation stabilization. Both products are manufactured from high-quality steel and undergo rigorous production processes and quality control to ensure excellent corrosion resistance and long service life. Whether it's a new construction project or a restoration project, choosing Mesh Masonry's anchor mesh products will provide reliable support and security for your project.
Product Parameters:
Parameters of reinforced mesh | |||
Mesh Size | Wire Diameter | Panel Sizes | |
In Inch | In MM | In MM | Common sizes: 2.2 x 5.8m, 2.0 x 2.9m
Other sizes can be made as request |
2” x 4” | 50 x 100mm | 4.0mm – 10.0mm | |
3” x 4” | 75 x 100mm | 4.0mm – 10.0mm | |
4” x 4” | 100 x 100mm | 4.0mm – 12.0mm | |
6” x 6” | 150 x 150mm | 4.0mm – 12.0mm | |
8” x 8” | 200 x 200mm | 4.0mm – 12.0mm | |
Advantages:
Fast construction, low labor intensity, good support effect, strong system stability
Material selection standard of steel mesh:
The technical specification stipulates that the welded mesh should be made of CRB550 grade cold rolled ribbed steel bar, and can also be made of CRB510 grade cold-drawn smooth steel bar. A piece of Welded Wire Mesh should be welded with the same type of steel bar. Welded wire mesh is classified into two types, fixed type and customized type, according to shape and specification. Customized welded wire mesh can have different spacing and diameters of reinforcement bars in two directions, but the reinforcement bars in the same direction should have the same diameter, spacing and length, which has been stipulated in the relevant standards and regulations. The shape and size of customized welded wire mesh should be determined according to the design and construction requirements, combined with the specific project conditions, by negotiation between the supply and demand sides.
The use of reinforcing steel mesh:
1, to protect the quality of the project, rigidity, good elasticity, high welding strength;
2、Improve seismic and crack-resistant performance, can reduce cracks;
3、Speed up the construction progress, improve the efficiency, can save working hours;
4, save the amount of rebar, alternative class I rebar can save steel 30% -40%;
5, reduce costs, reduce the cost of the project;
6、Wide range of uses, used in floor slabs, shear walls, bridge decks, mines, pavements, tunnels, holes in the ground, subways, airports.
Since the 20th century, welded steel mesh has been widely adopted by the construction industry as the reinforcement material for concrete structures.
